Product Description
- Feature
- Able to fit together with sensor, provide the inspection functions of oil back-up finishing and oil output finishing.
- Cylinder of ration is used; the oil output volume will not be affected by the difference of pressure, oil viscosity or temperature change.
- Able to adjust the range of oil output volume, easily applied to the rationing oil output of any industry.
- Usage
- NLGI No.0 No.3 grease, semi-solid or high-viscosity liquid.
Technical specification
|
Model
|
Dispensing volume (cm3/stroke)
|
Minimum operating pressure
Lubricant (MPa)
|
Minimum operating pressure
Barometric pressure
(MPa)
|
Operating pressure range
Lubricant
(MPa)
|
Operating pressure range
Barometric pressure
(MPa)
|
Bearable pressure on lubricant (MPa)
|
Grease range
|
Weight
|
|
APD2000
|
20200 c.c.
|
4.9(50kg)
|
0.3(3kg)
|
4.99.8(50100kg)
|
0.30.7(37kg)
|
11.8(120kg)
|
NLGI No.0No.3
|
7.7kg
|
Precision and Versatility in Fluid DispensingEngineered to meet the demands of industrial, laboratory, and assembly line operations, the 200 C.C. Precise Dispenser offers precise, adjustable dispensing with every stroke. Its compact, lightweight build ensures ease of use, while the compatible design works smoothly with several types of fluids, lubricants, and adhesives.
Designed for Efficiency and EaseThis dispenser operates using standard pneumatic air pressure (4-8 bar) with adjustable stroke speed, optimizing workflow and reducing operator fatigue. The precision nozzle enhances application control, resulting in cleaner and more accurate fluid delivery, making it suitable for delicate and repetitive tasks.
FAQ's of 200 C.C. Precise Dispenser:
Q: How can I adjust the dispensing volume with the 200 C.C. Precise Dispenser?
A: The dispensing volume is easily adjustable per stroke, allowing users to fine-tune the output according to specific requirements. Simply modify the stroke setting as indicated in the user manual for precise control over each application.
Q: What types of fluids are compatible with this dispenser?
A: This dispenser is designed to handle a wide variety of fluids, lubricants, and adhesives, making it an excellent choice for numerous industrial and laboratory applications.
Q: When is it beneficial to use the 200 C.C. Precise Dispenser?
A: This tool is particularly advantageous when precise, repeatable dispensing is necessary, such as during assembly line work, lab experiments, or when applying controlled amounts of adhesive or lubricant to components.
Q: Where can this dispenser be applied in an industrial environment?
A: It is suitable for use on assembly lines, in laboratory settings, and across various manufacturing processes where accurate and efficient fluid dispensing is required.
Q: What is the process for operating the dispenser?
A: To operate, simply connect the unit to a pneumatic air source (4-8 bar), adjust the stroke volume and speed as needed, and use the hand-held actuator to dispense the desired amount through the precision nozzle.
Q: Are there any significant benefits to choosing this model over manual dispensers?
A: Yes, the pneumatic operation provides greater consistency, adjustable speed and volume control, reduced fatigue, and superior accuracy, resulting in improved productivity and minimized material waste.
